OD1-AP Ophthalmic Ultrasound A Scanner/Pachymeter

OD1-AP Ophthalmic Ultrasound A-Scan & Pachymeter — CE & TUV Certified

Product Code: OD1-AP

The OD1-AP is a versatile, all-in-one ophthalmic ultrasound system that combines A-Scan biometry and Pachymetry in a single compact device. Whether you need precise axial length measurement for IOL calculations or reliable corneal thickness readings, the OD1-AP delivers accurate, repeatable results — backed by nearly 20 years of ultrasound research expertise.

Three Configurations Available:

• OD1-A — A-Scan Biometer
• OD1-P — Pachymeter
• OD1-AP — A-Scan & Pachymeter (combined system)

Key Features & Benefits

• Proven Ultrasound Technology: Nearly two decades of dedicated ultrasound research brings you the reliable OD1 series for ophthalmic biometry.
• 5.7" Color LED Touch Screen: Intuitive touch interface makes every operation faster and more convenient.
• Dual Measurement Methods: Supports both immersion and contact techniques for precise, flexible measurement.
• Built-in Thermal Printer: Print results instantly — no external printer needed.
• I-Station Software: Enables massive data storage, report transmission, and remote printing for efficient workflow management.
• High-Precision Results: Sensitive and accurate measurement displays 10 groups with deviation simultaneously for easy comparison.
• IOP Adjustment: Automatically adjusts calculations after entering tonometer measurement results for improved IOL accuracy.

A-Scan Specifications

• Probe: 10MHz red-light A-scan probe
• Resolution: 0.01mm
• Accuracy: ±0.1mm
• Gain Adjustable: 0–120dB
• Measurement Range: 15–35mm (velocity 1640m/s)
• Measurements: ACD (Anterior Chamber Depth), Lens, Vitreous, and AXL (Axial Length)
• Examination Modes: Normal, Cataract, Aphakic, and special eye models
• Measurement Mode: Immersion and contact; auto and manual
• IOL Formulas: SRK-II, SRK-T, TBINKHORST, HOLLADAY, HOFFER-Q, HAIGIS

Pachymeter Specifications

• Probe: 20MHz angled pachymeter probe
• Resolution: 1µm
• Measurement Range: 0.23–1.2mm
• Accuracy: ±0.005mm
• Measurement Points: Single or nine-point measurement with average reading for increased accuracy

Standard Configuration

1. Main unit
2. 10.0MHz A-scan probe
3. Gage block for A-scan/biometer
4. Power adapter
5. Touch screen pen
6. Screen size: 11.5 × 18.5 cm

Optional Components

• Large lithium battery
• Battery charger
• Immersion shell

Packing & Shipping Information

• Carton Size: 43 × 26 × 37 cm (0.0414 CBM)
• Net Weight: 1.7 kg | Gross Weight: 4.2 kg
• Device Dimensions: 16.5 (W) × 25 (H) × 16.5 (D) cm
